• System Size : 138W x 118D x 74.2H (mm)
  • Intel® Core™ i5-8265U Processor
  • 1 x RS232/422/485 COM Port
  • Dual Channel DDR4, 2 x SO-DIMMs
  • 2 x HDMI for Dual display
  • 2 x GbE LAN port
Dimension 138W x 118D x 74.2H(mm)

Intel® Core™ i5-8265U Processor
14nm, 4 cores, 8 threads, up to 3.9 GHz

Chipset SoC

2 x DDR4 SO-DIMM socket, Max. Capacity 64 GB
Support Dual Channel DDR4 2400 MHz memory modules

Ethernet 1 x GbE LAN port (Intel® i219V) ,1 x GbE LAN port (Realtek® RTL8111HS)
Graphic Support

Integrated Graphics Processor - Intel® UHD Graphics 620:
2 x HDMI 1.4 ports, supporting a maximum resolution of 4096x2160 @30Hz
(2 independent display outputs)

Audio Realtek® Audio Codec
Storage 1 x 2.5’’ HDD/SSD (SATA 6Gb/s)
Expansion Slots

1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Vertical USB 3.0

Front I/O

2 x USB 3.1 Gen2
1 x Power button with LED
2 x External Antenna (optional)
1 x COM port (RS-232/422/845)
1 x Headphone Jack

Rear I/O

2 x HDMI
2 x RJ45 LAN ports
2 x USB 3.1 Gen2
1 x Screw type DC Jack

Power +9~36VDC (Adapter 19V/90W)
Operation Temperature

Operating temperature: 0°C to 50°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature:-40°C to 85°C
Non-operating humidity: 0%-95% (non-condensing)
Use wide temperature range memory and storage

Vibration During Operation

Operation: IEC 60068-2-64, 5 Grms, random, 5 ~ 500 Hz, 1 hr / Per Axis, With SSD
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 hr / Per Axis

Shock During Operation

Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With SSD

Packaging Content

Box Packing Capacity: 6pcs
Carton size: 416x409x296(mm)
Power Cord : Optional (by region)
PSU ADP 19V 90W 100-240VAC x 1 (P/N: 25EP4-10090A-F3S)
Wall Mount Bracket (P/N: 25HB2-CGAA20-CHR)
Screw I Head for 2.5" HDD M3x8L x 4 (P/N: 25KSG-130081-K1R)
Thermal Pad HDD x 2 (P/N: 25ST3-200052-T5R)
Thermal Pad DRAM2 x 1 (P/N: 25ST3-200051-T5R)
SATA Power cable x 1 (P/N: 25CRI-075630-S9R)
SATA cable x 1 (P/N: 25CF4-075500-S9R)

Order Information

6BQB8265AMR-SI (Box packing)

Optional Kit

TPM 2.0 module P/N: 9CTM000NR-00
TPM Cable P/N: 25CRZ-100600-S9R
