• System Size: 178W x 125D x 52.7H(mm)
  • Intel® Celeron® J1900 Processor
  • Dual Channel DDR3L, 1 x SO-DIMM
  • HDMI, D-sub for Dual display
  • 2 x GbE LAN ports
Dimension 178W x 125D x 52.7H(mm)

Intel® Celeron® J1900 Processor
22nm, 4 cores, 4 threads, up to 2.42 GHz

Chipset SoC

1 x DDR3L SO-DIMM sockets, Max. Capacity 8 GB
Support Single Channel DDR3L 1333MHz memory modules

Ethernet 2 x GbE LAN ports (Intel® i211AT)
Graphic Support

Integrated Graphics Processor - Intel® HD Graphics:
1 x HDMI 1.4 port, supporting a maximum resolution of 1920x1200 @60Hz
1 x VGA port, supporting a maximum resolution of 2560x1600 @60Hz
(2 independent display outputs)

Audio Realtek® Audio Codec
Storage 1 x 2.5” HDD/SSD (SATA 3Gb/s)
Expansion Slots

1 x 2280 M.2 M-Key (SATA 3Gb/s)
1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G/4G module

Front I/O

2 x RJ45 LAN ports
1 x USB 3.0
1 x USB 2.0
1 x HDMI
1 x VGA
1 x Power switch
1 x Power & HDD LED
1 x Headphone jack

Rear I/O

2 x USB 2.0
2 x COM Ports (RS-232)
1 x COM Port (RS-232/422/485)
1 x COM Port (RS-232/422/485 and RI/5V/12V)
1 x 3 pin Terminal Block

Power +9~36VDC (Full Range)
Operation Temperature

Operating temperature: 0°C to 50°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -20°C to 70°C
Non-operating humidity: 0%-95% (non-condensing)
Use wide temperature range memory and storage

Vibration During Operation

Operation: IEC 60068-2-64, 5 Grms, random, 5 ~ 500 Hz, 1 hr / Per Axis, With SSD/M.2 2242
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 hr / Per Axis

Shock During Operation

Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With SSD

Packaging Content

Box Packing Capacity: 5pcs
Carton size: 505x333x231(mm)
Screw I Head for 2.5" HDD M3x8L x 4 (P/N: 25KSG-130081-K1R)
Thermal Pad x 2 (P/N: 25ST3-200052-T5R)
SATA cable x 1 (P/N: 25CF4-170020-S9R)
Terminal Blocks Male Plug x 1 (P/N: 25IO0-5ESDV0-D2R)

Order Information

6BQP1900AMR-SI (Box packing)

Optional Kit

TPM 2.0 module P/N: 9CTM000NR-00
TPM Cable P/N: 25CRZ-100600-S9R
