G492-Z51
- Up to 10 x PCIe GPGPU cards
- NVIDIA-Certified system for scalability, functionality, security, and performance
- AMD EPYC™ 7003 processors with AMD 3D V-Cache™ Technology
- AMD EPYC™ 7003 series processors
- Dual processor, 7nm technology
- 8-Channel RDIMM/LRDIMM DDR4 per processor, 32 x DIMMs
- 2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
- 1 x Dedicated management port
- 8 x 3.5" NVMe/SATA hot-swappable bays
- 4 x 3.5" SATA hot-swappable bays
- 10 x FHFL PCIe Gen4 x16 slots for GPUs
- 1 x LP PCIe Gen4 x16 slot
- 2 x LP PCIe Gen4 x16 slots on front side
- 1 x OCP 3.0 Gen4 x16 slot
- AST2500 Graphics & Remote Management controller
- 3 x 2200W 80 PLUS Platinum redundant power supplies
Interested in this product? Please contact one of our sales specialists!
Dimension | 448 x 176 x 880 |
---|---|
Motherboard | MZ52-G40 Rev. 3.0 |
CPU |
AMD EPYC™ 7003 processors with AMD 3D V-Cache™ Technology NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable Compatible with AMD EPYC™ 7002 series processors |
Chipset |
System on Chip |
Memory |
32 x DIMM slots Note: Follow BIOS setting and memory QVL list if running 3200 Mhz with 2DPC |
LAN |
Front side: 1 x 10/100/1000 management LAN |
Video |
Integrated in Aspeed® AST2500 |
Storage |
Front side: 4 x 3.5" SATA/SAS hot-swappable bays SAS card is required for SAS devices support |
SAS |
Depends on SAS card |
Expansion Slots |
10 x PCIe x16 (Gen4 x16) FHFL slots, from PEX88096, for GPUs (Broadcom solution) 1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth, from CPU_1 - System is validated for population with a uniform GPU model |
Internal I/O |
1 x TPM header |
Front I/O |
2 x USB 3.0 |
Backplane I/O |
Speed and bandwidth: |
TPM |
1 x TPM header with SPI interface |
Power Supply |
3 x 2200W 80 PLUS Platinum redundant power supplies AC Input: DC Input: DC Output: NOTE: The system power supply requires C19 type power cord |
System Management |
Aspeed® AST2500 management controller Dashboard |
OS Compatibility |
Windows Server 2016 (X2APIC/256T not supported) Red Hat Enterprise Linux 8.3 (x64) or later SUSE Linux Enterprise Server 12 SP5 (x64) or later Ubuntu 18.04.5 LTS (x64) or later VMware ESXi 6.7 Update3 P03 or later Citrix Hypervisor 8.2.0 or later |
System Fans |
4 x 40x40x28mm (25,000rpm) |
Operating Properties |
Operating temperature: 10°C to 35°C NOTE: Please contact Technical Support for more information about optimized GPU operating temperature |
Packaging Dimensions |
1109 x 609 x 606 mm |
Packaging Content |
1 x G492-Z51 |
Part Numbers |
- Barebone package: 6NG492Z51MR-00-A* |
